Volvo XC70 2012 - Page 245

TP 39217202 XC70(08-) & S80(07-) 2012 245
74/602 V70
14-pin gray
No. Floor harness Trunk lid harness
12/82:5 Relay, heated rear window
GY-RD
9/2A:1 Heated rear window
GY-RD
24/56C2:9Central Electronic Module
(CEM)
4/110C2:3 Trailer Module (TRM)
YE-GY
10/19:2 Auxiliary brake light
BK
34/56C2:59Central Electronic Module
(CEM)
GY-BN
73/6002 Branching point
BK
44/56C2:73Central Electronic Module
(CEM)
GN-BN
73/6003 Branching point
BK
54/56C2:54Central Electronic Module
(CEM)
BN-GN
73/6004 Branching point
BK
610/25:2Ceiling light, cargo
compartment
BU-BK
6/8:4 Central locking motor, trunk
lid
BK
773/5105Branching point
BK-OG
73/6001 Branching point
BK-OG
82/16:3 Relay, rear window wiper
GY-BU
6/32:1 Rear window wiper motor
BK
94/56C2:48Central Electronic Module
(CEM)
YE-VT
10/3:1 License plate lighting
YE-VT
10 -
-
-
-
11 4/56C2:63 Central Electronic Module
(CEM)
YE-OG
6/8:6 Central locking motor, trunk
lid
BK
12 4/56C2:24 Central Electronic Module
(CEM)
73/5032 Branching point
GN-YE
3/35:3 Switch, handle, trunk
lid/tailgate
GN-YE
13 4/56C2:30 Central Electronic Module
(CEM)
4/116C2:5 Power Operated Tailgate
Module (POT)
YE-OG
6/8:1 Central locking motor, trunk
lid
YE-OG
14 2/16:1 Relay, rear window wiper
VT-GN
6/32:2 Rear window wiper motor
BK
Connectors
74/602
