TP 39217202 XC70(08-) & S80(07-) 2012 246
74/603 V70
22-pin gray
No. Floor harness Trunk lid harness
1-
-
-
-
2-
-
-
-
3-
-
-
-
44/116C2:11Power Operated Tailgate
Module (POT)
YE-OG
6/8:3 Lock unit, tailgate V70
YE-OG
54/116C2:14Power Operated Tailgate
Module (POT)
GN-OG
6/149:1 Tailgate closing motor
GN-OG
64/116C2:7Power Operated Tailgate
Module (POT)
GN-BU
6/149:2 Tailgate closing motor
GN-BU
74/116C2:12Power Operated Tailgate
Module (POT)
GN
6/149:3 Tailgate closing motor
GN
8-
-
-
-
94/116C2:4Power Operated Tailgate Mod-
ule (POT)
GY-BN
3/291:1 Tailgate closing switch
GY-BN
10 73/5044 Branching point
BU-WH
3/291:5 Tailgate closing switch
BU-WH
11 -
-
-
-
12 -
-
-
-
13 -
-
-
-
14 -
-
-
-
15 4/93C1:22 Keyless Vehicle Module (KVM)
VT
16/132:2 Antenna door lock trunk
lid/tailgate
VT
16 4/93C1:21 Keyless Vehicle Module (KVM)
GN-OG
16/132:1 Antenna door lock trunk
lid/tailgate
GN-OG
17 -
-
-
-
18 -
-
-
-
19 -
-
-
-
20 -
-
-
-
21 -
-
-
-
22 -
-
-
-
74/1500
2-pin gray
No. Harness massage seats Harness supply refrigeration box
111C/25:2Fuses in distribution box
passenger compartment
RD
74/5001:3 Connector
2/141:1 Refrigeration box relay
PK
231/TRMGround connection,
Accessories
BK
2/141:2 Refrigeration box relay
17/19:2 12 V outlet, cargo
compartment
31/48 Ground connection
74/5001:2 Connector
BK-GN
Connectors
74/603 - 74/1500
