TP 39217202 XC70(08-) & S80(07-) 2012 247
74/1501
3-pin gray
No. Harness supply refrigeration box Harness refrigeration box
12/141:5Refrigeration box relay
RD
9/24:1 Refrigeration box
RD
29/24:2 Refrigeration box
10/276:2 Lighting center armrest
rear 1
10/277:2 Lighting center armrest
rear 2
10/280:2 Lighting cooler
compartment left
10/281:2 Lighting cooler
compartment right
BK
17/19:2 12 V outlet, cargo compartment
2/141:2 Refrigeration box relay
74/5000:2 Connector
BK-GN
374/5000:1Connector
2/141:1 Refrigeration box relay
PK
10/276:1 Lighting center armrest rear 1
10/277:1 Lighting center armrest rear 2
10/280:1 Lighting cooler compartment left
10/281:1 Lighting cooler compartment
right
PK
74/1502
2-pin green
No. Harness lighting mug holder Harness lighting floor
174/403:7Connector
10/72:1 Front ashtray lighting
10/161:1 Lighting mug holder
BU-RD
74/1503:1 Connector
10/286:1 Lighting floor driver’s side
10/287:1 Lighting floor passenger side
BU-RD
273/5026Branching point
10/72:2 Front ashtray lighting
10/161:2 Lighting mug holder
BK-VT
74/1503:2 Connector
10/286:2 Lighting floor driver’s side
10/287:2 Lighting floor passenger side
BK-VT
74/1503
2-pin green
No. Harness analog clock Harness lighting floor
1 19/4:1 Analog clock
BU-RD
74/1502:1 Connector
10/286:1 Lighting floor driver’s side
10/287:1 Lighting floor passenger side
BU-RD
2 19/4:2 Analog clock
BK-VT
74/1502:2 Connector
10/286:2 Lighting floor driver’s side
10/287:2 Lighting floor passenger side
BK-VT
Connectors
74/1501 - 74/1503
