TP 39217202 XC70(08-) & S80(07-) 2012 310
Component illustrations
7/116 - 7/143
7/116 Side impact sensor, right B-post
7/118 Height sensor, suspension, front left
7/119 Height sensor, suspension, front right
7/120 Height sensor, suspension, rear left
7/121 Height sensor, suspension, rear right
7/123 Clutch pedal sensor
7/124 Sensor brake pedal
7/130 Fuel level sensor, ejector side
7/131-
7/134 Rear parking assistance sensor
7/143 Sensor fuel level, pump side
