TP 39217202 XC70(08-) & S80(07-) 2012 340
Component illustrations
31/48 - 31/89
31/48 Ground connection, Right rear
bumper abutment
31/65 Ground connection, Rear seat riser,
left side 1
31/66 Ground connection, Rear seat riser,
left side 2
31/67 Ground connection, Rear seat riser,
right side 1
31/68 Ground connection, Rear seat riser,
right side 2
31/83 Ground connection, Left bottom rail
31/84 Ground connection, Right bottom rail
31/88 Ground connection, Engine ignition
coils, 5-Cyl.
31/88 Ground connection, Engine ignition
coils, 6-Cyl.
31/89 Ground connection, Engine ignition
coils, 5-Cyl.
