Installation Pipe System
TITANUS
MICRO·SENS
®
142
06/13
Air sampling
pipe
halogen free
Air sampling
pipe
(PVC)
Cleaning agent Adhesive Pipe cutter
ABSR-2518,
ABSR-3220,
ABSR-4025
R-2519,
R-3218,
R-4019
Tangit
cleaner
Tangit
adhesive
Pipe cutter or
38 mm saw
WARNING
Adhesives and cleaning products contain solvents and are flammable. It is
essential to observe the supplier’s safety information before processing.
3. Keep the pipe lengths and direction changes to a minimum. Elbows and
bends have an extremely high flow resistance. Use them only where this
is unavoidable. Should this be necessary, the pipe length must then be
reduced in relation to the fitted bends (an elbow equals a straight piece
of pipe of 1.5m).
NOTICE
Arcs should be used instead of elbows. An excessive number of bends and
angles reduce the air velocity in the air sampling pipe and thus increase the
detection time.
4. The pipes must be installed in such a way that they do not sag or move.
They are fixed with pipe clips without rubber core. The space between
the pipe clips should be no more than 80 cm. Reduce the space between
clips to no more than 30 cm if there are high temperature variations.
NOTICE
Do not use pipe clips with rubber cores as these do not expand lengthwise
and the pipes would sag or crack.
5. Close open pipe ends with end caps.
