Commissioning
TITANUS MICRO·SENS
®
170
06/13
Air flow sensor adjustment
NOTICE
Air flow initialising for the TITANUS MICRO·SENS
®
is completed success-
fully if a stable status for temperature and air flow is set for a period of 2
minutes. The maximum duration is 2 hours.
Air flow initialising for the TITANUS
MICRO·SENS
®
is completed success-
fully if for a period of 2 minutes the following status is set:
▪ the temperature oscillates by less than 0.1 K and,
▪ the air flow does not oscillate too much (temperature regulation) and,
▪ the fan voltage can be set properly, ventilator and fan power supply
working normally.
The maximum duration is 2 hours.
Air flow initialising is interrupted immediately if any of the following errors oc-
cur:
▪ Temperature measurement defective
▪ Air flow measurement defective
▪ Fan control defective
▪ Adjustment can be conducted independently of the current air pressure.
The restrictions for this kind of adjustment can be found in Chapter De-
sign "Air Flow Monitoring".
▪ The air flow sensor can be adjusted as a function of the current air pres-
sure.
In order to be able to assess the air flow sensor figure correctly during main-
tenance work, record the type of adjustment in each case in the test records.
8.3
Types of adjustment
