Technical Description
TITANUS
MICRO·SENS
®
38
06/13
Network Modules
Figure 18: Network card NU-2
The log data and status information of all TITANUS
®
air sampling smoke de-
tection systems can be stored with the TITANUS
®
network card. For applica-
tions in cold storage, special network modules for the TITANUS
®
available.
The TITANUS
®
network module is available in various configurations for the
respective areas:
Type
Application
TCP/IP SNMP Webserver Datenlogger Deep freezer
NU-2 X X X
NU-2-D X X X X
NU-2-DO X
NU-2-D-F X X X X X
NU-2-DO-F X X
With the help of this standard transfer protocol, the TITANUS
®
air sampling
smoke detection system can be connected to the risk management system
(e.g Visu
LAN
). All status information, as well as event and log data are
available as to the risk management.
The status information and log data stored in network cards on all TITANUS
®
air sampling smoke detection systems can be accessed via the SNMP pro-
tocol. By installing SNMP management software, customers can constantly
visualise and monitor the TITANUS
®
air sampling smoke detection systems.
When an incident occurs (e.g. a threshold is exceeded), an alert or a fault
message is sent to a managing entity or directly to another network partici-
pant via SNMP-Traps.
The integrated data logger is used to record event data (alerts and faults)
and log data (smoke level, air flow, air flow temperature, detection status,
temperature sensors) from TITANUS
®
air sampling smoke detection system.
The event and log data are saved on a memory card at pre-defined logging
3.2.5
Variants
TCP/IP
SNMP
Data logge
