TITANUS MICRO·SENS
®
Commissioning
06/13
173
Testing the detection unit and alarm forwarding
Trigger the TITANUS MICRO·SENS
®
and test the transmission route to the
FAS as follows:
1. Spray the test aerosol either into the first aspiration aperture or into the
TITANUS
MICRO·SENS
®
pipe system test adapter.
2. Proceed on the basis of the following table.
Check whether ... If this is not the case ...
the alarm on the air sampling smoke detection
system is displayed.
check whether the display plate is connected.
there is a fault in the air sampling smoke
detector
change the detection unit.
the alarm is transmitted to the FAS and noti-
fied on the associated line.
check the transmission routes.
NOTICE
If the LOGIC· SENS is set to “ON” in the “Settings” screen of the diagnostics
tool (see Chapter Installation "Settings"), then this must be set to "OFF" for
testing triggering the alarm with the test aerosol, in order to speed up alarm
assessment.
NOTICE
Note all test data in the test record.
8.4
