Technical Description
TITANUS
MICRO·SENS
®
26
06/13
Function
Air samples are taken from the area to be monitored via a pipe system with
defined aspiration apertures, using the TITANUS
MICRO·SENS
®
aspiration
unit and these are sent to the sensitive detection unit (see the following fig-
ure).
It is possible to locate the site of the fire using ROOM·IDENT with an I-pipe
design for a maximum 5 rooms or pieces of equipment. The operating prin-
ciple incorporates four phases:
During operating conditions air samples are taken from the pipes covering
the various rooms. The samples are taken via fan to the detector unit and
analysed for possible smoke particles.
Figure 5: Phase 1 ROOM·IDENT standard operation
The system will activate an alarm once it has reached an alarm threshold
level due to the rise of typical smoke aerosols. If „Fire alarm after
ROOM·IDENT“ is enabled, then the localisation process will start after an ad-
justable Action - Alarm threshold. The system will activate an alarm once the
localisation is completed.
3.1.1
Locating the site of the fire
Phase 1
Phase 2
