TITANUS MICRO·SENS
®
Design
06/13
69
The following sensitivities can be adjusted with the different detection units.
Sensitivity Sensitivity
Standard
Adjustment levels
Detection unit
DM-TM-10 0.1 - 2 % /m 0.1 % /m 0.1 % /m
Detection unit
DM-TM-50 0.5 - 2 % /m 0.5 % /m 0.1 % /m
Project planning for the monitored surface is always carried out according to
national specifications for point-shaped smoke detectors.
Design Limits
The following limit values must always be observed with the TITANUS MI-
CRO·SENS
®
:
▪ The minimum pipe length between 2 aspiration apertures is 0.1 m.
▪ The minimum pipe length between 2 aspiration apertures when locating
a fire is 3 m.
▪ The maximum pipe length between 2 aspiration apertures is 10 m.
▪ The maximum monitoring surface area per aspiration aperture corre-
sponds to the monitoring area of a point-specific alarm according to the
regulations in the particular national standards.
▪ Maximum 8 aspiration apertures are possible (Designs / design forms
not given in the manual are to be requested).
▪ Maximum 5 aspiration apertures are possible with site of a fire location.
The maximum overall monitoring surface area for the TITANUS
MI-
CRO·SENS
®
and the maximum overall pipe length depend on the design
chosen.
max. overall monitoring surface area per
TITANUS MICRO·SENS
®
max. design pipe length *
400 m²
Pipe ∅ 25 mm: 50 m
plus
Pipe ∅ 12 mm: 8 x 3 m
*Depending on the design chosen, restricted values apply in part.
NOTICE
Because of country-specific regulations, there may be restrictions com-
pared to the design limits in the manual!
5.1.5
