Technical Data
TITANUS MICRO·SENS
®
58
06/13
Device connection Clips for
0,5 - 2,5 mm²- wires
Cable pair twisted
Cable feeds
Detection box base
Detection box base floor
8 x M 20
2 x M 25
4 x M 25
conical
Pipe plug-in connections
2 x for aspiration pipe
∅ 25 mm
Detection unit
DM-TM-10 0.1 to 2.0 % light obscuration/m
DM-TM-50 0.5 to 2.0 % light obscuration/m
Accessories TITANUS MICRO·SENS
®
Parallel display for
TITANUS MICRO·SENS
®
Voltage
Nominal voltage 24 V
Power consumption (at 24 V)
Idle
maximum
15 mA
50 mA
electr. connection lengths max. 1000 m
Dimension (H x W x D mm) 70 x 140 x 200 mm
Weight 0.6 kg
Protection class (EN 60 529) IP 54
Material Plastic (ABS)
Colour papyrus white, RAL 9018
Parallel display – 20° to +60°C
Connections
Reaction sensitivit
y
4.3
Parallel displa
y
Dimension
Weigh
t
Protection class
Housing
Temperature range
