Design
TITANUS
MICRO·SENS
®
76
06/13
Aperture diameter
The aperture diameters of the aspiration apertures can be found in the cor-
responding table for the respective pipe configuration:
Figure 39: I-pipe system
Number of apertures 1 2 3 4 5
Aspiration aperture in mm*
A
B
C
D
E
6,8
5,0
5,0
4,2
4,2
4,4
3,4
3,6
3,8
4,4
3,0
3,2
3,4
3,6
4,4
*) Press cut diameter in aspiration-reducing film sheet
Figure 40: U-pipe system
Number of apertures 2 4 6 8
Aspiration aperture in mm*
A
B
C
D
6,0
4,2
4,6
3,4
3,4
4,4
3,0
3,0
3,6
4,0
*) Press cut diameter in aspiration-reducing film sheet
5.2.4
I-pipe
A
spiration apertures
U-pipe
A
spiration apertures
