Commissioning
TITANUS MICRO·SENS
®
166
06/13
Plug and Play Commissioning
With Plug and Play commissioning the standard settings are not changed.
Air flow adjustment happens automatically when the detection unit is put in
place.
NOTICE
If air flow adjustment is to happen automatically when the detection unit is
inserted, the Jumper X4 (PIN 1,2 or PIN 2,3) must be changed.
When the TITANUS
MICRO·SENS
®
is initialising, the green operating dis-
play flashes. When initialising is complete, the operating display changes to
a permanent light.
During the initialising phase, the TITANUS
MICRO·SENS
®
air flow should
not be influenced.
Figure 106: Inserting the detection unit into the device base
Commissioning with the diagnostics tool
If the diagnostics tool is used for commissioning, the pre-set settings can be
changed.
Air flow adjustment can then be carried out in either an air pressure-
dependent or an air pressure-independent manner. Air flow initialising is
8.1.1
8.1.2
