TITANUS
MICRO·SENS
®
Maintenance
06/13
193
Changing the filter on the SF 400/650 special
filter
Figure 111: Changing the filter element
To change the filter element, proceed as follows:
1. Loosen the two PVC transition threaded joints on the special filter (1a)
and remove it (1b).
2. Loosen both screwed plugs on the filter housing.
3. Remove the old filter element. Put the new filter element into the filter
housing.
4. Screw both screwed plugs to the filter housing.
5. Replace the special filter in the pipe system and fix it with the PVC tran-
sition threaded joints.
NOTICE
When the special filter is being installed, pay attention to the through flow
direction!
9.7
