WAGNER Titanus Micro-Sens - 5.2.2 Pipe Accessories Overview; 5.2.3 Sensitivity and Pipeline Project Planning

TITANUS MICRO·SENS
®
Design
06/13
71
Pipe accessories
Type Application Examples
LF-AD Coarse filter for separating
particles > approx. 15 µm
Dust, insects, fibres,
hair, cinders, pollen
LF-AD-1 Filter for separating
particles > approx. 10 µm
As above. Additionally:
Colour pigments and fine dust
LF-AD-2 Fine filter for separating
particles > approx. 5 µm
As above. Additionally:
Fine dust in low concentrations
SF-400 Fine filter for separating
particles > approx. 1 µm
As above. Additionally:
Fine dust in high concentrations
SF-650 Fine filter for separating
particles > approx. 1 µm
As above, but with
increased filter lifetime
Type Application
KA-DN-25 Condensation separator for applications with condensation moisture in
the pipe
KA-1 Condensation separator for applications with condensation moisture in
the pipe
Typ Application
SD-1 Sound suppressor for areas sensitive to noise
Typ Application
AVK-PV Stop valve for VSK cleaning air nozzle
AVK-PV-F Stop valve for VSK cleaning air nozzle for use in freezer areas
Sensitivity and pipeline project planning
Pipeline project planning with pipe accessories
The following project planning tables for pipeline project planning can be
found in the appendix for each previously selected pipe accessory.
▪ Project planning without filter
▪ Project planning with LF-AD air filter
▪ Project planning with LF-AD-1 air filter
▪ Project planning with LF-AD-2 air filter
▪ Project planning with SF-400 / SF-650 air filter
5.2.2
A
ir filters
Steam trap
Sound suppresso
r
Stop valve
5.2.3
5.2.3.1
