Installation Pipe System
06/13
141
Installation Pipe System
General assembly
The pipes, hoses and fittings used for the pipe system must always meet
requirements for Class 1131 in accordance with EN 61386-1, 2004.
Class 1131 puts the following requirements on the pipe system used:
Characteristics Severity code
Compression resistance 125 N
Impingement resistance 0.5 kg, drop height at 100 mm
Temperature range -15 °C to +60 °C
In principle, the following pipes as well as the related fittings are to be used
in configuring the pipe system:
External diameter Internal diameter
ABS
Internal diameter
PVC
Air sampling pipe 25 mm 21.4 mm 21.2 mm
Air sampling hose
(Typ SCH-P-25)
25 mm - 18.5 mm
Air sampling hose
(Typ SCH-PG-16)
21.1 mm 16.4 mm -
WARNING
Take note of the temperature range specified in the “Technical data” chap-
ter under “Pipe system” when configuring the pipe system.
Mounting pipe system
The pipe system must be designed according to the requirements of the pro-
ject and the pipe design guidelines (see chapter Design "Pipe Design").
1. Cut the pipes with a pipe cutter or a metal saw. Chips must be removed
and rough edges trimmed.
2. Before gluing, remove any dirt and grease from the joints with the rec-
ommended cleaning agent. Glue the pipe ends to the corresponding fit-
tings so that they are airtight.
