TITANUS MICRO·SENS
®
Commissioning
06/13
175
Testing fault forwarding
WARNING
The following steps can only be taken after air flow adjustment as de-
scribed in section "Air Flow Sensor Adjustment" has been carried out.
Test fault forwarding.
Check when testing air flow monitoring whether a fault is displayed on the
TITANUS
MICRO·SENS
®
and if applicable the FAS.
Testing the air flow sensor analysis function
If the TITANUS MICRO·SENS
®
cannot be adjusted, test how it is functioning
by means of a test pipe, a digital precision manometer, a PC and the diag-
nostics tool.
Complete function testing using the digital precision manometer is described
below. Limited function testing can also be carried out without the digital pre-
cision manometer.
8.6
8.7
