WAGNER Titanus Micro-Sens - Connecting the Network Module to the TITANUS MICRO·SENS

TITANUS MICRO·SENS
®
Installation
06/13
123
Connecting the network module to the TITANUS
MICRO·SENS
®
The network module connects the network to the TITANUS MICRO·SENS
®
.
The electrical connection required for the air sampling smoke detection sys-
tem circuit board is illustrated below.
NOTICE
The network may only be set up in consultation with the customer's system
administrator(s).
Figure 77: Connecting the TITANUS MICRO·SENS
®
6.8.2
