Commissioning
TITANUS MICRO·SENS
®
182
06/13
First the number of aspiration apertures then the blow through time and blow
through and aspiration fan voltage must be entered.
Click on the question mark for help.
? Blow through time help
Blow through time (for blow through fan voltage 13.5 V)
During blow through time the smoke is blown backwards out of the pipe. The
blow through time can be selected from the following table (intermediate val-
ues = next largest value):
Pipe Length (m) Time (secs)
10 80
15 97
20 113
25 130
30 147
35 163
40 180
1 second should be added to the blow through time for each pipe bend or
angle.
