Wittenborg FB 7100 - Page 101

Service Manual FB 7100 Programming
January, 2005 4- 59
Overall functions
Diagnostics/Test menu
Diagnostics/Test
Close the door
VMC Comm : OK SPC Comm : OK FB1 Comm : NOT OK
Cup ring : ON Upper opto : ON Lower opto : ON Safety switch : ON
!!!WARNING!!!
Please remove the
IN canisters
OK Esc
Sel Esc Sel Esc
V^
Wittlink test
Sel Esc
V^
Sensor test
Sel Esc
Full dispense test
Rinse in
progress
DISPENSING TEST
Sel Esc
V^
Test vend
Sel Esc
Cup handling
Sel Esc
V^
User interface
Press any button to escape Press any button to escape
4.3.11
4.3.11.1
4.3.11.2
