Service manual FB 7100 Programming
January, 2005 4- 81
4.3.11.2 Cup handling
In the submenu Cup handling, sensors related to the dispensing system are
tested.
General error
message
The following message may occur in the submenu of the Cup handling
menu: “No response from SPC. Check comm. and PCB”
The message appears if nothing has happened within 20 seconds after the
start of the test.
Possible causes: Wittlink error, defective print. Perform the Wittlink test
(see first test of the Diagnostic/Test menu).
4.3.11.3 User interface
The user interface submenu is a test of selection buttons, display, pre-
selection LEDs, doorlight, initialization text and coin return motor.
General error
message
The following message may occur in all of the submenus of the User
interface menu: ‘No response from SPC. Check comm. and PCB’
The message appears if nothing has happened within 20 seconds after the
start of the test.
Possible causes: Wittlink error, defective print. Perform the Wittlink test
(see first test of the Diagnostic/Test menu) and/or check print.
v Sel Esc^
Overall functions
* Cup handling
User interface
Sub menu Description
Sensor test The following sensors are tested:
• Lower opto: status On or Off.
To carry out the test of the sensor, an object, eg. a cup
or a pot must be placed on the platform or held in front
of the sensor and removed again. The status should
be “On” when the sensor detects an object, and “Off”
when it is removed.
If the status of the sensor does not switch from ‘On’ to
‘Off’ or vice versa when an object is inserted or
removed, it is an indication that the switch or sensor is
defect or not positioned correctly. Check the sensor
and replace if necessary.
See how sensor is replaced in chap. 5D, page 5D-1.
v Sel Esc^
Cup handling
* User interface
Water/Power/Heat
