Service manual FB 7100 Programming
4 - 82 January, 2005
Sub menu Description
Button/Key test Tests the operating panel buttons and key.
To perform the test:
• Press the coin return button. The status will change
from Off to On until released.
• Turn the Multibrew/Discount key. The status will
change from Off to On or vice versa.
• Press any selection, pre-selection, multibrew or
cancel button. The display will show the index
number of the pressed key until it is released.
To leave this menu wait for the system to time out after
10 seconds of inactivity. A timer shown in the lower
right corner of the display counts down from 10 to 0.
The message “Error!! Button hanging” is shown if a
button on the selection panel is stuck. In most cases it
will be sufficient to loosen the selection panel and
nudge the button into place again. If that, however,
does not help, the selection panel must be taken out
and the button(s) in question adjusted or replaced.
See how selection buttons are replaced in chap. 5G,
page 5G-7.
Display test Shows the selected character set used in the display.
The first window shows letters and numbers, the
second shows special characters.
A sure indicator that the wrong display has been
installed is if the arrow shown in the special characters
window does not have a proper arrow head.
Pre. sel. led test Tests the LEDs above the preselection buttons.
To perform the test, press ‘Sel’. The machine runs a
test of the LEDs from left to right. A beep will sound
when the test is completed.
Door light toggle Tests poster doorlight.
To perform the test, press ‘Sel’ to turn doorlight on or
off, (the display shows whether it is turned on or off).
Test Init. text Runs the initialization text, i.e. the text that is shown in
the display during power up of the machine or when it
is switching from menu to vend mode.
To perform the test, press ‘Sel’. The display will run the
initialization text. Press any button to stop the test.
