Service manual FB 7100 Programming
4 - 80 January, 2005
Full dispense test Note: During this test it is not required that the door is
closed.
The test will reveal if any of the components of the
dispensing system have been incorrectly assembled.
Press ‘Sel’ to start the test. The message ‘Please
remove the IN canisters’ now appears in the display.
You may either remove the canisters or ignore the
message and continue the test by pressing OK.
Note: If you run the test with the canisters still in
the machine, ingredient powder will be dropped
into the mixing funnels, but no water is used in this
test. Therefore, the funnels should be emptied
after the test.
A test of the individual parts of the dispensing system
is performed in the following order:
• Fan: Tests if fan is running correctly by turning it on
for five seconds.
• Pump: Tests if pump is running correctly by turning
it on for five seconds.
• Brewer: Brewer is closed and water pressed
through cylinder to check valve and dispenser
motor.
(In machines with two brewers, the right most
brewer is checked first).
• IN module: A five second test of each instant
module one at a time is carried out in the following
order from left to right: ingredient motor 1, whipper
1, water inlet into mixing funnel 1, ingredient motor
2, whipper 2 etc.
Note: If the test order varies from the left-to-right
order, e.g. if ingredient motor 3 starts before
ingredient motor 2, it is an indication that the
modules have been assembled incorrectly.
Test ven d
The Test vend option makes it possible to dispense
any of the available drinks for testing.
To perform the test, close the door. When the display
reads “DISPENSING TEST”, press any selection key to
have the machine dispense a test drink.
Sub menu Description
