NOTE: The latches that secure the Xerographic
Module to the Printer Frame are spring-loaded and
will automatically engage the holes. The latches have
a 1/4 turn lockout feature that may be used to prevent
actuation during reinstallation of the Xerographic
Module. When performing the following step, ensure
that the spring-loaded feature is active.
6. (Figure 2): Using the handles on the Web Oiler
Assembly, rotate the Xerographic Module 90
degrees so that the latches lock into the holes in
the frame.
. Rotate the Xerographic
Module 90 degrees
Ensure that the Xerographic
Module is latched to the Frame
Figure 2. Latching the Xerographic Module at the Service Position
8830
1/98
4-47
REP 9.2
