Xerox 8830 Service Manual

( To enterihe Diagnostic Mode
The^fgnostic mode is entered by pressing
and holding the zero (0) button while switching
on the printer. The Diagnostic Mode may also
be entered from the Control Panel by entering
the Printer Menu>,IOT Diagnostics, and
entering the password (6789).
When entering the diagnostic mode, the
Message Display will indicate the Copyright
message, the message ROM configuration,
and the software revision level.
The following message will be displayed when
the diagnostic mode is entered.
CHAIN 00 PRESS ENTER TO BEGIN
PLEASE ENTER THE CHAIN NUMBER
Enter the first two digits of the code and press
Enter button, then enter the second two digits
of the code, and press the Enter button to
begin the test.
The Control Panel buttons are identified in the
following diagram:
Previous Next Enter
The code entered will be displayed on the
Control Panel. The test name will be in the
bottom line of the display along with test
feedback information. There also may be
additional information displayed depending on
the test being run.
The Exit button is used to stop the tests.
The Exit button is used to clear the entry
The Test Codes consist of a chain number
and a test number. The chain numbers
correspond to the same chain numbers that
are used in the Service Manual to identify
functional areas in the printer. The test
numbers are sequential numbers to identify
the tests within a chain.
The chain numbers used are listed below
7. Press the Exit button again to clear the
chain
Chain
Number
01
02
03
04
06
07
08
09
10
11
14
Functional Area
Standby Power
User Interface (Control Panel)
Printer Run Control
Drives
Exposure
Media Supply
Media Transportation
Xerographies
Fusing/Print Transportation
Finishing
Communication
To exit the Diagnostic Mode
s^nter^the test [0361] or switch the printer
power off, wait 5 seconds, then switch it on.
input Diagnostic Test Procedure
1. Enter the Diagnostic Mode
2. Enter the Test Code
3. Press the Enter button to begin the test.
4. Manually operate the component that is to
be tested.
5. The condition of the component will be
indicated in the message display window.
The state of the component is indicated by
a 0 for low state and a 1 for high state
6. Press the Exit button to stop the
diagnostic test
Diagnostics
1/98
6-2
8830
