Xerox 8830 Service Manual

Input Diagnostic Test Codes
Code
[0101]
[0102]
[0103]
[0104]
[0105]
[0106]
[0202]
[0211]
[0701]
[0702]
[0707]
[0708]
Component Tested
Front Door Interlock
Line Voltage Sense
Line Frequency Sense
Line Voltage High/Low
Cut Sheet Feed Shelf Interlock
Top Cover Interlock
Keyboard Test
Message ROM Test
Module Loop Interlock (Media
Transport and Xero Mod
installed)
Cutter Drawer Interlock
Roll 1 Sensor Input
Roll 2 Sensor Input
Code
[0709]
[0710]
[0711]
[0712]
[0713]
[0714]
[0715]
[0721]
[0801]
[0802]
[0803]
[0807]
[0808]
[0901]
[0902]
[1005]
Component Tested
Roll 3 Sensor Input
Roll 1 Motion Sensor Input
Roll 2 Motion Sensor Input
Roll 3 Motion Sensor Input
Roll 1 Drawer Sensor Input
Roll 2 Drawer Sensor Input
Roll 3 Drawer Sensor Input
Cutter Home Sensor
Bypass Sensor
Buckle Sensor
Media Registration Sensor
Exit Sensor
Catch Tray Full Sensor (Stacker)
Toner (Cartridge) Home Sensor
Drum Motor Stall Sensor
Fuser Jam Switch
Code
[1008]
[1010]
Component Tested
Fuser Open Sensor
Fuser Scorch Sensor (To reset,
power OFF then ON)
8830
1/98
6-3
Diagnostics
