February 2013
4-326
ColorQube® 9303 Family
REP 91.4
Repairs/Adjustments
4. Remove the front and rear tensioner bases, Figure 3.
Figure 3 Tensioner base removal
Replacement
1. Replacement is the reverse of the removal procedure.
2. Figure 4 shows the correct route for the front and rear belts.
3. Ensure that both carriages are parked and the wiper is in the home position, all the way
up or down.
Figure 4 Belt routing
1
Remove the e-clip then
the rear tensioner base.
2
Remove the e-clip then the
front tensioner base.
Front Belt
Rear Belt
