February 2013
4-398
ColorQube® 9303 Family
ADJ 12.4-110
Repairs/Adjustments
NOTE: Check the belt condition and routing if the tension spring is not extended or the
locking screw is at the end of the bracket adjustment slot.
Figure 1 Drive Belt Tensioning
Typical spring tensioning arrangement
Drive belt
Bracket
Pivot Screw
Lock screw
Adjustment slot
Tension spring
