Xerox ColorQube 9301 - Page 1459

February 2013
6-167
ColorQube® 9303 Family
dC131
General Procedures/Information
604-721 ImeHead3YellRes
FillTimeoutFC
Fault counter for 93-560: IME
Head 3 Yellow reservoir fill tim
-
eout
Number of faults
Range = 0 to 255
0
604-722 ImeHead4BlkRes
FillTimeoutFC
Fault counter for 93-561: IME
Head 4 Black reservoir fill tim
-
eout
Number of faults
Range = 0 to 255
0
604-723 ImeHead4MagRe
sFillTimeoutFC
Fault counter for 93-562: IME
Head 4 Magenta reservoir fill
timeout
Number of faults
Range = 0 to 255
0
604-724 ImeHead4CyRes
FillTimeoutFC
Fault counter for 93-563: IME
Head 4 Cyan reservoir fill time
-
out
Number of faults
Range = 0 to 255
0
604-725 ImeHead4YellRes
FillTimeoutFC
Fault counter for 93-564: IME
Head 4 Yellow reservoir fill tim
-
eout
Number of faults
Range = 0 to 255
0
604-726 ImeHead1BlkRes
LevelFailFC
Fault counter for 93-565: IME
Head 1 Black reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-727 ImeHead1MagRe
sLevelFailFC
Fault counter for 93-566: IME
Head 1 Magenta reservoir
level sense failure
Number of faults
Range = 0 to 255
0
604-728 ImeHead1CyRes
LevelSense
-
FailFC
Fault counter for 93-567: IME
Head 1 Cyan reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-729 ImeHead1YellRes
LevelFailFC
Fault counter for 93-568: IME
Head 1 Yellow reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-730 ImeHead2BlkRes
LevelFailFC
Fault counter for 93-569: IME
Head 2 Black reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-731 ImeHead2MagRe
sLevelFailFC
Fault counter for 93-570: IME
Head 2 Magenta reservoir
level sense failure
Number of faults
Range = 0 to 255
0
604-732 ImeHead2CyRes
LevelSense
-
FailFC
Fault counter for 93-571: IME
Head 2 Cyan reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-733 ImeHead2YellRes
LevelFailFC
Fault counter for 93-572: IME
Head 2 Yellow reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-734 ImeHead3BlkRes
LevelFailFC
Fault counter for 93-573: IME
Head 3 Black reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-735 ImeHead3MagRe
sLevelFailFC
Fault counter for 93-574: IME
Head 3 Magenta reservoir
level sense failure
Number of faults
Range = 0 to 255
0
Table 12 CCS NVM ID 604-657 to 604-999
NVM ID NVM Name NVM Description Settings Default
604-736 ImeHead3CyRes
LevelSense
-
FailFC
Fault counter for 93-575: IME
Head 3 Cyan reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-737 ImeHead3YellRes
LevelFailFC
Fault counter for 93-576: IME
Head 3 Yellow reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-738 ImeHead4BlkRes
LevelFailFC
Fault counter for 93-577: IME
Head 4 Black reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-739 ImeHead4MagRe
sLevelFailFC
Fault counter for 93-578: IME
Head 4 Magenta reservoir
level sense failure
Number of faults
Range = 0 to 255
0
604-740 ImeHead4CyRes
LevelSense
-
FailFC
Fault counter for 93-579: IME
Head 4 Cyan reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-741 ImeHead4YellRes
LevelFailFC
Fault counter for 93-580: IME
Head 4 Yellow reservoir level
sense failure
Number of faults
Range = 0 to 255
0
604-742 ImeHead1BlkRes
Lev
-
elSenseOpenFC
Fault counter for 93-581: IME
Head 1 Black reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-743 ImeHead1MagRe
sLev
-
elSenseOpenFC
Fault counter for 93-582: IME
Head 1 Magenta reservoir
level sense open
Number of faults
Range = 0 to 255
0
604-744 ImeHead1CyRes
Lev
-
elSenseOpenFC
Fault counter for 93-583: IME
Head 1 Cyan reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-745 ImeHead1YellRes
Lev
-
elSenseOpenFC
Fault counter for 93-584: IME
Head 1 Yellow reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-746 ImeHead2BlkRes
Lev
-
elSenseOpenFC
Fault counter for 93-585: IME
Head 2 Black reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-747 ImeHead2MagRe
sLev
-
elSenseOpenFC
Fault counter for 93-586: IME
Head 2 Magenta reservoir
level sense open
Number of faults
Range = 0 to 255
0
604-748 ImeHead2CyRes
Lev
-
elSenseOpenFC
Fault counter for 93-587: IME
Head 2 Cyan reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-749 ImeHead2YellRes
Lev
-
elSenseOpenFC
Fault counter for 93-588: IME
Head 2 Yellow reservoir level
sense open
Number of faults
Range = 0 to 255
0
604-750 ImeHead3BlkRes
Lev
-
elSenseOpenFC
Fault counter for 93-589: IME
Head 3 Black reservoir level
sense open
Number of faults
Range = 0 to 255
0
Table 12 CCS NVM ID 604-657 to 604-999
NVM ID NVM Name NVM Description Settings Default
