Xerox ColorQube 9301 - Page 1505

February 2013
6-213
ColorQube® 9303 Family
dC131
General Procedures/Information
608-255 SolenoidInkPurge
ValveH4OpenFC
Fault Counter 99-603-00:
SOLENOIDINKPURGEVALVE
H4OPEN
Number of faults
Range = 0 to 255
0
608-256 SolenoidInkDose
ValveH1C1Open
FC
Fault Counter 99-604-00:
SOLENOIDINKDOSEVALVEH
1C1OPEN
Number of faults
Range = 0 to 255
0
608-257 SolenoidInkDose
ValveH1C2Open
FC
Fault Counter 99-605-00:
SOLENOIDINKDOSEVALVEH
1C2OPEN
Number of faults
Range = 0 to 255
0
608-258 SolenoidInkDose
ValveH1C3Open
FC
Fault Counter 99-606-00:
SOLENOIDINKDOSEVALVEH
1C3OPEN
Number of faults
Range = 0 to 255
0
608-259 SolenoidInkDose
ValveH1C4Open
FC
Fault Counter 99-607-00:
SOLENOIDINKDOSEVALVEH
1C4OPEN
Number of faults
Range = 0 to 255
0
608-260 SolenoidInkDose
ValveH2C1Open
FC
Fault Counter 99-608-00:
SOLENOIDINKDOSEVALVEH
2C1OPEN
Number of faults
Range = 0 to 255
0
608-261 SolenoidInkDose
ValveH2C2Open
FC
Fault Counter 99-609-00:
SOLENOIDINKDOSEVALVEH
2C2OPEN
Number of faults
Range = 0 to 255
0
608-262 SolenoidInkDose
ValveH2C3Open
FC
Fault Counter 99-610-00:
SOLENOIDINKDOSEVALVEH
2C3OPEN
Number of faults
Range = 0 to 255
0
608-263 SolenoidInkDose
ValveH2C4Open
FC
Fault Counter 99-611-00:
SOLENOIDINKDOSEVALVEH
2C4OPEN
Number of faults
Range = 0 to 255
0
608-264 SolenoidInkDose
ValveH3C1Open
FC
Fault Counter 99-612-00:
SOLENOIDINKDOSEVALVEH
3C1OPEN
Number of faults
Range = 0 to 255
0
608-265 SolenoidInkDose
ValveH3C2Open
FC
Fault Counter 99-613-00:
SOLENOIDINKDOSEVALVEH
3C2OPEN
Number of faults
Range = 0 to 255
0
608-266 SolenoidInkDose
ValveH3C3Open
FC
Fault Counter 99-614-00:
SOLENOIDINKDOSEVALVEH
3C3OPEN
Number of faults
Range = 0 to 255
0
608-267 SolenoidInkDose
ValveH3C4Open
FC
Fault Counter 99-615-00:
SOLENOIDINKDOSEVALVEH
3C4OPEN
Number of faults
Range = 0 to 255
0
608-268 SolenoidInkDose
ValveH4C1Open
FC
Fault Counter 99-616-00:
SOLENOIDINKDOSEVALVEH
4C1OPEN
Number of faults
Range = 0 to 255
0
608-269 SolenoidInkDose
ValveH4C2Open
FC
Fault Counter 99-617-00:
SOLENOIDINKDOSEVALVEH
4C2OPEN
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-270 SolenoidInkDose
ValveH4C3Open
FC
Fault Counter 99-618-00:
SOLENOIDINKDOSEVALVEH
4C3OPEN
Number of faults
Range = 0 to 255
0
608-271 SolenoidInkDose
ValveH4C4Open
FC
Fault Counter 99-619-00:
SOLENOIDINKDOSEVALVEH
4C4OPEN
Number of faults
Range = 0 to 255
0
608-272 SolenoidInkPurge
ValveH1ShortFC
Fault Counter 99-620-00:
SOLENOIDINKPURGEVALVE
H1SHORT
Number of faults
Range = 0 to 255
0
608-273 SolenoidInkPurge
ValveH2ShortFC
Fault Counter 99-621-00:
SOLENOIDINKPURGEVALVE
H2SHORT
Number of faults
Range = 0 to 255
0
608-274 SolenoidInkPurge
ValveH3ShortFC
Fault Counter 99-622-00:
SOLENOIDINKPURGEVALVE
H3SHORT
Number of faults
Range = 0 to 255
0
608-275 SolenoidInkPurge
ValveH4ShortFC
Fault Counter 99-623-00:
SOLENOIDINKPURGEVALVE
H4SHORT
Number of faults
Range = 0 to 255
0
608-276 SolenoidInkDose
ValveH1C1ShortF
C
Fault Counter 99-624-00:
SOLENOIDINKDOSEVALVEH
1C1SHORT
Number of faults
Range = 0 to 255
0
608-277 SolenoidInkDose
ValveH1C2ShortF
C
Fault Counter 99-625-00:
SOLENOIDINKDOSEVALVEH
1C2SHORT
Number of faults
Range = 0 to 255
0
608-278 SolenoidInkDose
ValveH1C3ShortF
C
Fault Counter 99-626-00:
SOLENOIDINKDOSEVALVEH
1C3SHORT
Number of faults
Range = 0 to 255
0
608-279 SolenoidInkDose
ValveH1C4ShortF
C
Fault Counter 99-627-00:
SOLENOIDINKDOSEVALVEH
1C4SHORT
Number of faults
Range = 0 to 255
0
608-280 SolenoidInkDose
ValveH2C1ShortF
C
Fault Counter 99-628-00:
SOLENOIDINKDOSEVALVEH
2C1SHORT
Number of faults
Range = 0 to 255
0
608-281 SolenoidInkDose
ValveH2C2ShortF
C
Fault Counter 99-629-00:
SOLENOIDINKDOSEVALVEH
2C2SHORT
Number of faults
Range = 0 to 255
0
608-282 SolenoidInkDose
ValveH2C3ShortF
C
Fault Counter 99-630-00:
SOLENOIDINKDOSEVALVEH
2C3SHORT
Number of faults
Range = 0 to 255
608-283 SolenoidInkDose
ValveH2C4ShortF
C
Fault Counter 99-631-00:
SOLENOIDINKDOSEVALVEH
2C4SHORT
Number of faults
Range = 0 to 255
0
608-284 SolenoidInkDose
ValveH3C1ShortF
C
Fault Counter 99-632-00:
SOLENOIDINKDOSEVALVEH
3C1SHORT
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
