6-218
ColorQube® 9303 Family
dC131
General Procedures/Information
608-419 Cal parameter out
of range
Fault Counter 89-566-00: CAL-
IBRATIONPARAMETER-
OUTOFRANGE
Number of faults
Range = 0 to 255
0
608-420 Head1 Black Rev
Lev FP Excep.
Fault Counter 93-909-00:
HEAD1BLACKRESERVOIRL
EVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-421 Head1 Magenta
Rev Lev FP
Excep.
Fault Counter 93-910-00:
HEAD1MAGENTARESERVOI
RLEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-422 Head1 Cyan Rev
Lev FP Excep
Fault Counter 93-911-00:
HEAD1CYANRESERVOIRLE
VSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-423 Head1 Yellow
Rev Lev FP
Excep.
Fault Counter 93-912-00:
HEAD1YELLOWRESERVOIR
LEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-424 Head2 Black Rev
Lev FP Excep.
Fault Counter 93-913-00:
HEAD2BLACKRESERVOIRL
EVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-425 Head2 Magenta
Rev Lev FP
Excep.
Fault Counter 93-914-00:
HEAD2MAGENTARESERVOI
RLEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-426 Head2 Cyan Rev
Lev FP Excep.
Fault Counter 93-915-00:
HEAD2CYANRESERVOIRLE
VSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-427 Head2 Yellow
Rev Lev FP
Excep.
Fault Counter 93-916-00:
HEAD2YELLOWRESERVOIR
LEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-428 Head3 Black Rev
Lev FP Excep.
Fault Counter 93-917-00:
HEAD3BLACKRESERVOIRL
EVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-429 Head3 Magenta
Rev Lev FP
Excep.
Fault Counter 93-918-00:
HEAD3MAGENTARESERVOI
RLEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-430 Head3 Cyan Rev
Lev FP Excep.
Fault Counter 93-919-00:
HEAD3CYANRESERVOIRLE
VSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-431 Head3 Yellow
Rev Lev FP
Excep.
Fault Counter 93-920-00:
HEAD3YELLOWRESERVOIR
LEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-432 Head4 Black Rev
Lev FP Excep.
Fault Counter 93-921-00:
HEAD4BLACKRESERVOIRL
EVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-433 Head4 Magenta
Rev Lev FP
Excep.
Fault Counter 93-922-00:
HEAD4MAGENTARESERVOI
RLEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
608-434 Head4 Cyan Rev
Lev FP Excep.
Fault Counter 93-923-00:
HEAD4CYANRESERVOIRLE
VSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-435 Head4 Yellow
Rev Lev FP
Excep.
Fault Counter 93-924-00:
HEAD4YELLOWRESERVOIR
LEVSENSFPEXCEPTION
Number of faults
Range = 0 to 255
0
608-436 Oil Delivery pump
stall
Fault Counter 94-617-00:
OILDELIVERYPUMPSTALL
Number of faults
Range = 0 to 255
0
608-437 Oil Removal
pump stall
Fault Counter 94-618-00: OIL-
REMOVALPUMPSTALL
Number of faults
Range = 0 to 255
0
608-438 MaintenanceKit-
InstallDate
Current Maintenance Kit Install
Date
Range = 0 to
4294967295
0
608-450 CleaninUnitPre-
matureOilLowFC
Fault Counter 94-616-00:
CLEANINGUNITPREMA
-
TUREOILLOW
Number of faults
Range = 0 to 255
0
608-451 CleanUni-
tOilLineBlock-
ageFC
Fault Counter 94-619-00:
CLEANINGUNI
-
TOILLINEBLOCKAGE
Number of faults
Range = 0 to 255
0
608-452 EarlyConfirmTim-
eOutFC
Fault Counter 82-161-00:
EARLYCONFIRMTIMEOUT
Number of faults
Range = 0 to 255
0
608-453 ESDCount1Exce
ededFC
Fault Counter 92-527-00:
ESDCOUNT1EXCEEDED
Number of faults
Range = 0 to 255
0
608-454 ESDCount2Exce
ededFC
Fault Counter 92-528-00:
ESDCOUNT2EXCEEDED
Number of faults
Range = 0 to 255
0
608-455 ExcessivePaper-
SkewFC
Fault Counter 91-669-00:
ExcessivePaperSkew
Number of faults
Range = 0 to 255
0
608-456 Scanned Image
Out Of
SequenceFC
Fault Counter 91-670-00:
Scanned Image Out Of
Sequence
Number of faults
Range = 0 to 255
0
608-457 Fiducials could
not be foundFC
Fault Counter 91-671-00: Fidu-
cials could not be found
Number of faults
Range = 0 to 255
0
608-458 Too Many missing
JetsFC
Fault Counter 91-672-00: Too
Many missing Jets
Number of faults
Range = 0 to 255
0
608-459 Floating Point
ErrorFC
Fault Counter 91-673-00:
Floating Point Error
Number of faults
Range = 0 to 255
0
608-460 HD1 adjustment
exceeds maxFC
Fault Counter 91-674-00: HD1
adjustment exceeds max
Number of faults
Range = 0 to 255
0
608-461 HD2 adjustment
exceeds maxFC
Fault Counter 91-675-00: HD2
adjustment exceeds max
Number of faults
Range = 0 to 255
0
608-462 HD3 adjustment
exceeds maxFC
Fault Counter 91-676-00: HD3
adjustment exceeds max
Number of faults
Range = 0 to 255
0
608-463 HD4 adjustment
exceeds maxFC
Fault Counter 91-677-00: HD4
adjustment exceeds max
Number of faults
Range = 0 to 255
0
608-464 HD1 adjust con-
verge failedFC
Fault Counter 91-678-00: HD1
adjust converge failed
Number of faults
Range = 0 to 255
0
Table 17 CCS NVM ID 608-xxx
NVM ID NVM Name NVM Description Settings Default
