February 2013
7-8
ColorQube® 9303 Family
PJ Locations
Wiring Data
Power Supply Unit
Location: PL 1.15 Item 2
Figure 1 Power supply unit
Table 12 PJDC1 to PJDC4
PJ number PJ location figure PJ location
Wiring
diagram
DC1 Figure 1 Power Supply Unit WD 1.4
DC2 Figure 1 Power Supply Unit WD 1.4
DC3 Figure 1 Power Supply Unit WD 1.5
DC4 Figure 1 Power Supply Unit WD 1.5
