February 2013
7-17
ColorQube® 9303 Family
PJ Locations
Wiring Data
Solenoid Patch PWB
Location: PL 93.10 Item 9.
Figure 18 Solenoid patch PWB
Ink Load Entry PWB
Location: PL 93.10 Item 8.
Figure 19 Ink load entry PWB
