February 2013
3-50
ColorQube® 9303 Family
IQ 13
Image Quality
Figure 4 Jet to jet non-uniformity
Figure 5 Jet to jet non-uniformity on dithers
Procedure
NOTE: Before printing the test pages, ensure that A4 or 8.5 x 11 inch plain paper is loaded
long edge feed into tray 4. Use the best quality media available. Do not use hole punched
paper.
Evaluate the cyan / magenta test page and the red, blue and green bands in the colour bands
print (TP 1). Check for distinctive non-uniform bands in the process direction.
The prints are
good and are without non-uniform bands.
YN
Perform the following dC972 Print Head Uniformity routines:
1. Option 3 Head to head uniformity
2. Option 4 TRC Generation
3. Option 5 Y-dot position correction
Print TP 1. Evaluate the cyan / magenta test page and the red, blue and green bands on
the colour bands test page for distinctive non-uniform bands in the process direction.
The prints are good and are without non-uniform bands.
YN
Perform the following dC972 Print Head Uniformity routines:
B C
To Next Page
