Yamaha F40B - Page 109

67C3K11 5-14
1
2
3
4
5
6
7
8
9
No.
Part name Q’ty Remarks
18 10-pin main harness 1 E and W model
19 Bolt 8 M8 × 80 mm
20 Bolt 2 M6 × 16 mm
21 Screw 2 ø6 × 25 mm
22 Nut 2
23 Apron 1
24 Bolt 4 M6 × 25 mm/M and W model
25 Bolt 1 M6 × 18 mm/M and W model
26 Grommet 1 M and W model
27 Plastic tie 2
28 Clamp 1
29 Clip 3
30 Washer 1
S67C5040
8
2
9
11
12
14
20
13
3
23
4
1
7
18
21
24
24
29
29
30
25
26
27
28
27
22
19
10
15
20
17
16
5
6
29
BOW
LT
572
LT
T
R
.
.
21 N
·
m (2.1 kgf
·
m, 15.5 ft
·
Ib)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
Power unit
