Yamaha F40B - Power Unit; Power Unit Assembly

POWR
Power unit
5-13 67C3K11
Power unit
Power unit assembly
No.
Part name Q’ty Remarks
1 Manual starter 1 M and W model
2 Driven sprocket cover 1 M and W model
3 Flywheel magnet cover 1 E model
4 Oil dipstick 1
5 Throttle cable 1
6 Shift cable 1
7 Start-in-gear protection cable 1 M and W model
8 Power unit 1
9 Cooling water hose 1
10 Cooling water hose 1
11 Positive battery cable 1 E and W model
12 PTT relay lead 2 PTT model
13 Bolt 1 M6 × 12 mm/E and W model
14 Negative battery cable 1 E and W model
15 Fuel hose 1
16 Gasket 1
Not reusable
17 Dowel 2
S67C5040
8
2
9
11
12
14
20
13
3
23
4
1
7
18
21
24
24
29
29
30
25
26
27
28
27
22
19
10
15
20
17
16
5
6
29
BOW
LT
572
LT
T
R
.
.
21 N
·
m (2.1 kgf
·
m, 15.5 ft
·
Ib)
T
R
.
.
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
