Bow view
+ E and W model
, M model
1 CDI unit
2 Starter motor (E and W model)
3 Rectifier Regulator (E and W model)
4 10-pin main harness coupler (E and W model)
5 Battery cable (E and W model)
6 10-pin main harness (E and W model)
7 Warning indicator assembly lead (H model
with electric starter)
8 Warning indicator assembly (M model)
9 Engine shut-off switch lead (M model)
S67C8005
6
3
1
2
4
75
98
+
,
Electrical component and wiring harness routing
