67C3K11 7-22
1
2
3
4
5
6
7
8
9
8. Install the dowels M and oil pan assem-
bly N, and then tighten the upper case
bolts O to the specified torque.
9. Install the upper mount P, and then
tighten the bolts Q.
È S-transom model
10. Install the damper and engine oil drain
bolt R, and then tighten the drain bolt to
the specified torque.
Removing the steering arm
1. Remove the circlip 1, and then remove
the steering yoke 2 using a general
puller 3.
2. Remove the steering arm 4 from the
swivel bracket 5 by pulling the arm off
the bracket.
È S-transom model
É L-transom model
NOTE:
To disassemble the clamp brackets, see
“Removing the clamp bracket” (7-29).
T
R
.
.
Upper case bolt O:
21 N·m (2.1 kgf·m, 15.5 ft·lb)
T
R
.
.
Engine oil drain bolt R:
17 N·m (1.7 kgf·m, 12.5 ft·lb)
S67C7027
AA
AA
AA
LT
572
LT
LT
572
LT
M
M
O
O
P
Q
R
È
N
General puller 3:
(commercially available)
S67C7028
4
5
2
1
2
È
S67C7130
2
3
È
S67C7129
2
3
É
Upper case and steering arm
