Yamaha F40B - PTT Motor

67C3K11 7-34
1
2
3
4
5
6
7
8
9
PTT motor
No.
Part name Q’ty Remarks
1 PTT motor assembly 1
2Stator 1
3Screw 2 ø4 × 10 mm
4O-ring 1
Not reusable
5 Armature 1
6Screw 1 ø4 × 8 mm
7Screw 2 ø4 × 10 mm
8Spring 2
9 Brush 1 Long lead
10 Brush 1 Short lead
11 Bolt 4 M6 × 20 mm
12 PTT motor base 1
13 Oil seal 1
Not reusable
14 O-ring 1
Not reusable
15 Spring 1
16 Shaft connector 1
17 Reservoir cap 1
S67C7059
9
6
8
10
5
7
8
9
13
10
a
a
b
b
17
3
9
8
7
2
11
11
11
6
1
5
3
4
12
13
15
16
14
10
8
7
T
R
.
.
7 N
·
m (0.7 kgf
·
m, 5.2 ft
·
Ib)
T
R
.
.
7 N
·
m (0.7 kgf
·
m, 5.2 ft
·
Ib)
Clamp bracket and swivel bracket / PTT motor
