Yamaha F40B - Installing the Power Unit

67C3K11 5-52
1
2
3
4
5
6
7
8
9
11. Install the union bolt E and tighten it to
the specified torque.
12. Install the oil filter F, and then tighten it
to the specified torque using a 64 mm
(2.5 in) oil filter wrench.
NOTE:
• Before installing the oil filter F, be sure to
supply engine oil to the oil passages g.
• Apply a thin coat of engine oil to the O-ring
of the oil filter F before installation.
13. Install new gaskets, the exhaust cover
G, the thermostat, and the thermostat
cover H, and then tighten the bolts to the
specified torques in 2 stages and in the
sequence shown.
Installing the power unit
1. Clean the power unit mating surface.
2. Install the dowels 1, a new gasket 2,
and the power unit 3, and then tighten
the mounting bolts 4 to the specified
torque.
CAUTION:
Do not reuse the gasket, always replace it
with a new one.
T
R
.
.
Crankcase bolt 1–8 (M8):
1st: 15 N·m (1.5 kgf·m, 11.1 ft·lb)
2nd: 30 N·m (3.0 kgf·m, 22.1 ft·lb)
Crankcase bolt 9–F (M6):
1st: 6 N·m (0.6 kgf·m, 4.4 ft·lb)
2nd: 12 N·m (1.2 kgf·m, 8.9 ft·lb)
Oil filter wrench: 90890-01426
T
R
.
.
Union bolt E:
40 N·m (4.0 kgf·m, 29.5 ft·lb)
Oil filter F:
18 N·m (1.8 kgf·m, 13.3 ft·lb)
S67C5157
g
E
E
E
F
T
R
.
.
Exhaust cover bolt 1–6, 8, 0:
1st: 6 N·m (0.6 kgf·m, 4.4 ft·lb)
2nd: 12 N·m (1.2 kgf·m, 8.9 ft·lb)
Thermostat cover bolt 7, 9:
7 N·m (0.7 kgf·m, 5.2 ft·lb)
T
R
.
.
Power unit mounting bolt 4:
21 N·m (2.1 kgf·m, 15.5 ft·lb)
S67C5158
0
4
7
6
5
3
2
9
8
G
H
1
S67C5159
BOW
4
4
4
4
1
3
2
LT
572
LT
LT
572
LT
Cylinder block
