Yamaha F40B - Timing Belt and Sprocket

67C3K11 5-22
1
2
3
4
5
6
7
8
9
Timing belt and sprocket
No.
Part name Q’ty Remarks
1 Nut 1 Width across flats: 30 mm
2 Washer 1
3Bolt 4 M6 × 10 mm/M and W model
4 Starter hub 1 M and W model
5 Flywheel magnet 1
6Bolt 3 M5 × 25 mm/M model/M5 × 30 mm/E and W
model
7 Stator assembly 1
8 Spring washer 1
9 Timing belt 1
10 Drive sprocket 1
11 Woodruff key 1
12 Woodruff key 1
13 Bolt 1 M10 × 40 mm
14 Washer 1
15 Driven sprocket 1
16 Dowel 1
S67C5048
6
12
10
16
8
5
4
3
1
3
2
1
6
6
7
9
11
14
13
15
2
E
LT
242
T
R
.
.
6 N
·
m (0.6 kgf
·
m, 4.4 ft
·
Ib)
T
R
.
.
157 N
·
m (15.7 kgf
·
m, 115.8 ft
·
lb)
T
R
.
.
38 N
·
m (3.8 kgf
·
m, 28.0 ft
·
Ib)
E
Power unit / Timing belt and sprocket
