67C3K11 1-2
1
2
3
4
5
6
7
8
9
Symbol
The symbols below are designed to indicate the content of a chapter.
General information
Specification
Periodic check and adjustment
Fuel system
Power unit
Lower unit
Bracket unit
Electrical system
Troubleshooting
GEN
INFO
SPEC
CHK
ADJ
FUEL
POWR
LOWR
BRKT
ELEC
TRBL
SHTG
– +
Symbols 1 to 6 indicate specific data.
1 Special service tool
2 Specified oil or fluid
3 Specified engine speed
4 Specified tightening torque
5 Specified measurement
6 Specified electrical value
(resistance, voltage, electric current)
Symbols 7 to C in an exploded diagram or illustration indicate the grade of lubricant and the lubri-
cation point.
7 Apply 4-stroke motor oil
8 Apply gear oil
9 Apply water resistant grease (Yamaha grease A)
0 Apply molybdenum disulfide grease
A Apply corrosion resistant grease
(Yamaha grease D)
B Apply low temperature resistant grease
(Yamaha grease C)
C Apply injector grease
Symbols D to I in an exploded diagram or illustration indicate the type of sealant or locking agent
and the application point.
D Apply Gasket Maker
E Apply ThreeBond 1104J
F Apply LOCTITE 271 (red)
G Apply LOCTITE 242 (blue)
H Apply LOCTITE 572
I Apply silicone sealant
123456
T
R
.
.
7890ABC
E G
A M D C I
DEFGHI
GM
1104J
271
LT
242
LT
572
LT
SS
How to use this manual
