Yamaha F40B - Page 183

67C3K11 7-2
1
2
3
4
5
6
7
8
9
No.
Part name Q’ty Remarks
1 Engine start switch 1 E and W model
2 Plug 1 M model
3 Engine shut-off switch 1
4 Cover 1
5 10-pin main harness 1 E and W model
6 Warning indicator harness 1 E and W model
7Screw 2 ø6 × 19 mm/E and W model
8 Warning indicator assembly 1 E and W model
9 Plate 1 E and W model
10 Warning buzzer 1 E and W model
11 Bracket 1 E and W model
12 Bolt 1 M6 × 14 mm/E and W model
13 Screw 1 ø6 × 16 mm/PTT model
14 PTT switch 1 PTT model
15 Grip end 1
16 Screw 1 ø6 × 16 mm
17 Clamp 2 E and W model
S67C7119
3
16
15
2
1
3
13
1
9
4
65
8
7
7
10
11
12
17
14
1
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
17
Tiller handle (H model)
