SPEC
Specification
2-13 67C3K11
Fuel control system
Prime Start resistance
(*1)
(Y – Y)
at 20 °C (68 °F) Ω 20.0–23.0
Prime Start plunger length
(*1)
mm (in) 10.7 (0.42)
Starting system
Power bobbin output peak
voltage (Y/B – Y/B)
at cranking (loaded) V 7.0
at 1,500 r/min (loaded) V 28.0
at 3,500 r/min (loaded) V 77.7
Power bobbin resistance
(*2)
(Y/B – Y/B)
at 20 °C (68 °F) Ω 6.5–7.2
Starter motor
Type — Bendix
Output kW — 1.20
Cranking time limit Second — 30
Brushes
Wear limit mm (in) — 6.4 (0.25)
Commutator
Undercut wear limit mm (in) — 0.8 (0.03)
Charging system
Fuse A — 20
Lighting coil output peak
voltage (Y – Y)
at cranking (unloaded) V 14.1 8.4
at 1,500 r/min (unloaded) V 39.7 28.5
at 3,500 r/min (unloaded) V 95.2 66.6
Lighting coil resistance
(*2)
(Y – Y)
at 20 °C (68 °F) Ω 0.90–1.10 0.26–0.28
Rectifier Regulator output
peak voltage (R – Ground)
at 1,500 r/min (loaded) V — 13
at 3,500 r/min (loaded) V — 13
(*1)
The following resistance is when the ambient temperature is 20 °C (68 °F) and there is no power supplied.
The figures are for reference only.
(*2)
The figures are for reference only.
Item Unit
Model
F30AMHD F40BMHD F40BWHD F40BED
