67C3K11 2-20
1
2
3
4
5
6
7
8
9
Fuel control system
Prime Start resistance
(*1)
(Y – Y)
at 20 °C (68 °F) Ω 20.0–23.0
Prime Start plunger length
(*1)
mm (in) 10.7 (0.42)
Starting system
Power bobbin output peak
voltage (Y/B – Y/B)
at cranking (loaded) V 7.0
at 1,500 r/min (loaded) V 28.0
at 3,500 r/min (loaded) V 77.7
Power bobbin resistance
(*2)
(Y/B – Y/B)
at 20 °C (68 °F) Ω 6.5–7.2
Starter motor
Type Bendix
Output kW 1.20
Cranking time limit Second 30
Brushes
Wear limit mm (in) 6.4 (0.25)
Commutator
Undercut wear limit mm (in) 0.8 (0.03)
Charging system
Fuse A 20
Lighting coil output peak
voltage (Y – Y)
at cranking (unloaded) V 8.4
at 1,500 r/min (unloaded) V 28.5
at 3,500 r/min (unloaded) V 66.6
Lighting coil resistance
(*2)
(Y – Y)
at 20 °C (68 °F) Ω 0.26–0.28
Rectifier Regulator output
peak voltage (R – Ground)
at 1,500 r/min (loaded) V 13
at 3,500 r/min (loaded) V 13
(*1)
The following resistance is when the ambient temperature is 20 °C (68 °F) and there is no power supplied.
The figures are for reference only.
(*2)
The figures are for reference only.
Item Unit
Model
F30AEHT F30AET F40BWHT F40BET
Maintenance specification
