Yamaha F40B - Page 86

FUEL
Fuel system
4-11 67C3K11
No.
Part name Q’ty Remarks
18 O-ring 1
Not reusable
19 Pilot screw 1 For Europe
20 Pilot screw 1 For Oceania
21 Gasket 1
Not reusable
22 Float 1
23 Float pin 1
24 Screw 1 ø4 × 8 mm
25 Screw 1 ø3 × 6 mm
26 Plunger 1
27 Spring 1
28 Float chamber 1
29 Screw 4 ø4 × 14 mm
S67C4018
3
12
8
7
6
5
4
9
29
23
25
21
22
13
14
15
16
26
27
10
11
27
26
24
28
2
1
1
17
18
19 20
