Factory Recommended Branch Circuit Protection
WARNING! Fire Hazard. Install adequate branch circuit protection according to applicable local codes and this manual. Failure to comply
could result in fire and damage to the drive or injury to personnel. The device is suitable for use on a circuit capable of delivering not more
than 100,000 RMS symmetrical amperes, 240 Vac (200 V class) and 480 Vac (400 V class), when protected by branch circuit protection
devices specified in this manual.
Branch circuit protection shall be provided by any of the following: Non-time delay Class J, T, or CC fuses sized at 300% of the drive input
rating, or Time delay Class J, T, or CC fuses sized at 175% of the drive input rating, or MCCB sized at 200% maximum of the drive input
rating.
Yaskawa recommends installing one of the following types of branch circuit protection to maintain compliance with UL508C.
Semiconductor protective type fuses are preferred. Alternate branch circuit protection devices are also listed in Table 6.3.
Table 6.3 Factory Recommended Z1000 AC Drive Branch Circuit Protection
Model
Nominal Output
Power (HP)
AC Drive Input
(A)
MCCB Rating (A)
<1>
Time Delay Fuse
Rating (A)
<2>
Non-time Delay
Fuse Rating (A)
<3>
Bussmann
Semiconductor
Fuse Model
(Fuse Ampere)
<4>
Three-Phase 200 V Class
2A0011 3 10.6 20 17.5 30 FWH-40B (40)
2A0017 5 16.7 30 25 50 FWH-50B (50)
2A0024 7.5 24.2 40 40 70 FWH-80B (80)
2A0031 10 30.8 60 50 90 FWH-100B (100)
2A0046 15 46.2 90 80 125 FWH-150B (150)
2A0059 20 59.4 110 100 175 FWH-175B (175)
2A0075 25 74.8 150 125 200 FWH-225A (225)
2A0088 30 88 175 150 250 FWH-225A (225)
2A0114 40 114 225 175 300 FWH-250A (250)
2A0143 50 143 250 250 400 FWH-275A (275)
2A0169 60 169 300 275 500 FWH-350A (350)
2A0211 75 211 400 350 600 FWH-400A (400)
2A0273 10 273 500 450
<5>
FWH-450A (450)
2A0343 125 343 600 600 FWH-600A (600)
2A0396 150 396 700
<5>
FWH-600A (600)
Three-Phase 400 V Class
4A0005 3 4.8 15 8 12 FWH-40B (40)
4A0008 5 7.6 15 12 20 FWH-40B (40)
4A0011 7.5 11 20 17.5 30 FWH-45B (45)
4A0014 10 14 25 20 40 FWH-45B (45)
4A0021 15 21 40 35 60 FWH-60B (60)
4A0027 20 27 50 45 80 FWH-60B (60)
4A0034 25 34 60 50 100 FWH-125B(125)
4A0040 30 40 75 70 110 FWH-150B (150)
4A0052 40 52 100 90 150 FWH-200B (200)
4A0065 50 65 125 110 175 FWH-225A (225)
4A0077 60 77 150 125 225 FWH-225A (225)
4A0096 75 96 175 150 275 FWH-225A (225)
4A0124 100 124 225 200 350 FWH-250A(250)
4A0156 125 156 300 250 450 FWH-300A (300)
4A0180 150 180 350 300 500 FWH-350A (350)
4A0240 200 240 450 400
<5>
FWH-400A (400)
4A0302 250 302 600 500 FWH-600A (600)
4A0361 300 346 600
600 1000
<6>
FWH-800A (800)
4A0414 350 410 800 700
1200
<6>
FWH-800A (800)
6.5 Installing Peripheral Devices
256
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
