YASKAWA Z1000 User Manual

Model Product Code Product Text Parts List
Weight
kg (lb)
Recommended Mounting Hardware
(Not Provided)
Screw Size
Tightening Torque
N·m (lb. in.)
Three-Phase 400 V Class
4A0005
4A0008
4A0011
100-065-941 72606 -EZZ021642A
Bracket (Qty. 2)
Attachment (Qty. 1)
Screw M5x14+S+W (Qty. 8)
1.1 (2.43) Screw M5x14 (Qty. 10)
2.0 to 2.5
(17.7 to 22.1)
4A0014
4A0021
4A0027
100-065-942 72606 -EZZ021642B
Bracket (Qty. 2)
Attachment (Qty. 1)
Screw M5x14+S+W (Qty. 8)
1.4 (3.09) Screw M5x14 (Qty. 12)
2.0 to 2.5
(17.7 to 22.1)
4A0034
4A0040
100-065-943 72606 -EZZ021642C
Bracket 1 (Qty. 2)
Bracket 2 (Qty. 2)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 2)
Screw M5x14+S+W (Qty. 10)
1.9 (4.19) Screw M6x14 (Qty. 12)
4.0 to 4.9
(35.4 to 43.3)
4A0052
4A0065
4A0077
4A0096
100-065-944 72606 -EZZ021642D
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Bracket 3 (Qty. 1)
Bracket 4 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 2)
Screw M5x14+S+W (Qty. 8)
Screw M6x14+S+W (Qty. 2)
2.4 (5.29) Screw M6x14 (Qty. 14)
4.0 to 4.9
(35.4 to 43.3)
4A0124 100-065-945 72606 -EZZ021642E
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 11)
Screw M5x14+S+W (Qty. 10)
4.2 (9.26)
Screw M5x20 (Qty. 12)
Screw M8x20 (Qty. 4)
M5: 2.0 to 2.5
(17.7 to 22.1)
M8: 9.0 to 10.7
(79.7 to 94.6)
4A0156
4A0180
4A0240
100-065-946 72606 -EZZ021642F
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 12)
Screw M5x14+S+W (Qty.12)
4.8 (10.58)
Screw M5x20 (Qty. 12)
Screw M10x20 (Qty. 4)
M5: 2.0 to 2.5
(17.7 to 22.1)
M10: 17.7 to 22.5
(156.7 to 199.1)
4A0302 100-065-947 72606 -EZZ021642G
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 16)
Screw M5x14+S+W (Qty. 16)
6.8 (14.99)
Screw M5x20 (Qty. 16)
Screw M12x20 (Qty. 4)
M5: 2.0 to 2.5
(17.7 to 22.1)
M12: 31.4 to 39.2
(277.9 to 346.9)
6.5 Installing Peripheral Devices
262
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
