Model
Dimensions mm (in)
Figure W H W1 H1 H2 H3 H4 H5 A B
4A0014
4A0021
4A0027
1 170 (6.69) 465 (18.31) 150 (5.91) 445 (17.52) – – – – 118 (4.65) 414 (16.30)
4A0034
4A0040
2 200 (7.87) 533 (20.98) 130 (5.12) 520 (20.47) – – – – 194 (7.64) 473 (18.62)
4A0052
4A0065
4A0077
4A0096
2 305 (12.01) 570 (22.44) 285 (11.22) 555 (21.85) – – – – 239 (9.41) 508 (20.00)
4A0124 3 276 (10.87)
721.4
(28.40)
170 (6.69)
705.4
(27.77)
20.5 (0.81) 9 (0.35) 21.9 (0.86) 7 (0.28) 259 (10.20) 663 (26.10)
4A0156
4A0180
4A0240
4 340 (13.39) 803 (31.61) 244 (9.61) 781 (30.75) 24.2 (0.95) 11.5 (0.45) 30.8 (1.21) 10.5 (0.41) 326 (12.83) 726 (28.58)
4A0302 5 455 (17.91)
1065
(41.93)
325 (12.80)
1038
(40.87)
28 (1.10) 14 (0.55) 29 (1.14) 13 (0.51) 435 (17.13) 981 (38.62)
n
NEMA Type 12 Heatsink-External Mounting Attachment
Table 6.7 shows the heatsink-external mounting attachment for a NEMA Type 12 enclosure.
Order parts according to the corresponding product codes in Table 6.7 and install them according to document EZZ021642.
NEMA Type 12 attachments are available only for rev.B or later products. Contact a Yaskawa sales representative for product
revisions. Refer to Table 6.9 for panel cut-out dimensions.
NOTICE: Tighten the installation screws for the bracket and the attachment to the specified tightening torque. Dust can enter if the screw
is loose, and may cause the drive to break down.
NOTICE: Do not damage the gasket when installing the bracket and attachment. Water and dust can enter when the bracket and attachment
are installed incorrectly, and may cause the drive to break down.
NOTICE: The bracket and attachment must match the direction of the installation. Water and dust can enter when the bracket and attachment
are installed incorrectly, and may cause the drive to break down.
Table 6.7 NEMA Type 12 Attachment Code List
Model
Product Code Product Text Parts List
Weight
kg (lb)
Recommended Mounting Hardware
(Not Provided)
Screw Size
Tightening Torque
N·m (lb. in.)
Three-Phase 200 V Class
2A0011
2A0017
100-065-941 72606 -EZZ021642A
Bracket (Qty. 2)
Attachment (Qty. 1)
Screw M5x14+S+W (Qty. 8)
1.1 (2.43) Screw M5x14 (Qty. 10)
2.0 to 2.5
(17.7 to 22.1)
2A0024
2A0031
100-065-942 72606 -EZZ021642B
Bracket (Qty. 2)
Attachment (Qty. 1)
Screw M5x14+S+W (Qty. 8)
1.4 (3.09) Screw M5x14 (Qty. 12)
2.0 to 2.5
(17.7 to 22.1)
2A0046
2A0059
100-065-943 72606 -EZZ021642C
Bracket 1 (Qty. 2)
Bracket 2 (Qty. 2)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 2)
Screw M5x14+S+W (Qty. 10)
1.9 (4.19) Screw M6x14 (Qty. 12)
4.0 to 4.9
(35.4 to 43.3)
2A0075
2A0088
2A0114
100-065-944 72606 -EZZ021642D
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Bracket 3 (Qty. 1)
Bracket 4 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 2)
Screw M5x14+S+W (Qty. 8)
Screw M6x14+S+W (Qty. 2)
2.4 (5.29) Screw M6x14 (Qty. 14)
4.0 to 4.9
(35.4 to 43.3)
2A0143
2A0169
2A0211
2A0273
100-065-946 72606 -EZZ021642F
Bracket 1 (Qty. 1)
Bracket 2 (Qty. 1)
Attachment (Qty. 1)
Screw M4x10+S+W (Qty. 12)
Screw M5x14+S+W (Qty.12)
4.8 (10.58)
Screw M5x20 (Qty. 12)
Screw M10x20 (Qty. 4)
M5: 2.0 to 2.5
(17.7 to 22.1)
M10: 17.7 to 22.5
(156.7 to 199.1)
6.5 Installing Peripheral Devices
YASKAWA ELECTRIC TOEP C710616 45F YASKAWA AC Drive – Z1000 User Manual
261
6
Peripheral Devices &
Options
